272 Brocade Virtual ADX Graphical User Interface Guide
53-1003242-01
XML schema element reference
B
mask.subnet IP subnet The VLAN IP subnet's
mask in address form 15 characters maximum; if
provided, cannot be blank;
"length" and "subnet" are
mutually-exclusive
ipSubnet.name string The VLAN IP subnet
name 32 characters maximum;
optional
ipSubnet.dynamicProtocol boolean The VLAN "dynamic
protocol" option flag default false; either
dynamicProtocol or
staticProtocol must exist,
but not both; they are
mutually-exclusive, but at
least one of them is
required
ipSubnet.staticProtocol container The VLAN "static
protocol" options Either dynamicProtocol or
staticProtocol must exist,
but not both; they are
mutually-exclusive, but at
least one of them is
required
staticProtocol.ethernetPorts container The VLAN "static
protocol" ethernet
ports Multiple "ethernetPort"
elements are allowed, up
to 64 maximum
ethernetPorts.
ethernetPort integer An ethernet port in the
static protocol 1 to 64, or possibly less
than 64 depending on the
valid port numbers of the
current ADX
staticProtocol.routerInterface integer The router interface in
the static protocol 1 to 64, or possibly less
than 64 depending on the
valid port numbers of the
current ADX; optional
ipSubnet.excludeProtocol container The VLAN "exclude
protocol" options Optional
excludeProtocol.ethernetPort
s container The VLAN "exclude
protocol" ethernet
ports Multiple "ethernetPort"
elements are allowed, up
to 64 maximum
ethernetPorts.
ethernetPort integer An ethernet port in the
static protocol 1 to 64, or possibly less
than 64 depending on the
valid port numbers of the
current ADX
vlan.spanningTree boolean The VLAN "spanning
tree" flag Default false; optional
vlan.alwaysActive boolean The VLAN "always
active" flag Default false; optional
vlan.routerInterface integer The VLAN router
interface 1 to 64, or possibly less
than 64 depending on the
valid port numbers of the
current ADX; optional
network.tcpProfiles container A collection of TCP
Profile definitions Optional
TABLE 90 Network schema elements (Continued)
Element Type Description Rules / Notes
