Virtual servers
13
Virtual server ports
To view the virtual server port statistics on the Brocade Virtual ADX, perform the following steps
within the Monitor tab.
1. Click Traffic on the menu bar.
2. From the sidebar, select Virtual Servers.
3. Click Ports at the bottom of the Virtual Servers page.
A new All Virtual Server Ports page is displayed, as shown in Figure 148 .
FIGURE 148 Displaying the virtual server ports
The following table describes the fields available in the Virtual Server Ports page.
TABLE 62 Virtual Server Ports page - fields and descriptions
Field Description
Name Displays the name of the virtual server port.
Status Displays the health of the virtual server ports. The health status
can be one of the following:
•
Up
•
Down
Admin State Displays the admin state of the virtual server ports. The port status
can be one of the following:
•
Healthy
•
Unhealthy
Current Connections Displays the number of current open connections on the virtual
server ports.
