XML schema element reference
B
real.realPorts container A collection of Real Ports Optional
realPorts.realPort container A single Real Server Port Multiple "realPort" elements
are allowed up to
32 maximum
realPort.port port-or-protocol
-number The name of a well known
port or a protocol number
•
http
•
https
•
ssl
•
dns
•
ftp
•
ldap
•
ldaps
•
tftp
•
ssh
•
1 to 65535
realPort.port.@variable string attribute The name of a variable that
provides the port name or
protocol number Must refer to an existing
variable of type
"portOrProtocol"; optional
realPort.periodicHC boolean The periodic health check
flag for the port Default is false; optional
realPort.ehcName string The element health check
name for the port Optional
realPort.portPolicyName string The port policy name for the
port Optional
realPort.serverId integer The server ID for the port 1024 to 5119; optional
realPort.serverId.@variable string attribute The name of a variable that
provides a server ID Must refer to an existing
variable of type "integer" or
"integerNonZero"; optional
realPort.groupIds container A collection of Group IDs for
the port Optional
groupIds.groupId container A range of group ID numbers Multiple "groupId" elements
are allowed up to 4
maximum
groupId.from integer The beginning of group ID
range 0 to 1023; "from" must not
be greater than "to"; if
"@variable" is used, set a "0"
placeholder value here
groupId.from.@variable string attribute The name of a variable that
provides a beginning group
ID Must refer to an existing
variable of type "integer" or
"integerNonZero" whose
value is 0 to 1023; "from"
must not be greater than
"to"; optional
groupId.to integer The end of group ID range 0 to 1023; "to" must not be
less than "from"; if
"@variable" is used, set a "0"
placeholder value here
TABLE 92 Real server schema elements (Continued)
Element Type Description Rules / Notes
