Brocade Virtual ADX Graphical User Interface Guide 217
53-1003242-01
Content switching
13
Content switching
You can view the summary of all the Layer 7 content switching rules and policies configured on the
Brocade Virtual ADX.
Content switching policies
To display the statistics of all the content switching policies configured on the Brocade Virtual ADX,
perform the following steps within the Monitor tab.
1. Click Traffic on the menu bar.
2. From the sidebar, select Content Switching.
The CSW Policy tab is displayed, as shown in Figure 154 .
FIGURE 154 CSW Policy tab
The following table describes the fields available in the CSW Policy tab.
TABLE 68 CSW Policy tab - fields and descriptions
Field Description
Name Displays the name of the Layer 7 content switching policy.
Type Displays the type of the rule assigned for the Layer 7 content
switching policy. The types can be one of the following:
•
HTTP request - Indicates the content switching policy is of
Hypertext Transfer Protocol (HTTP) request type for incoming
traffic.
•
HTTP response - Indicates the content switching policy is of
HTTP response type for outgoing traffic.
Rx Packets Displays the total number of packets received on the port.
Created Sessions Displays the total number of created sessions for this policy.
Session Drops Displays the total number of dropped sessions for this policy.
