Management Applications
Using stack-unit, slot number, and port numberwith CLI commands..............................22
Supported management application features
Lists the management application features supported on FastIron devices.
The following table lists the individual BrocadeFastIron switches and the management application
features they support. These features are supported in the Layer 2 and Layer 3 software images.
Feature
ICX 6430
ICX 6450
FCX
ICX 6610
ICX 6650
FSX 800
FSX 1600
ICX 7750
Management port
08.0.01
08.0.01
08.0.01
08.0.01
08.0.01
08.0.01
08.0.10
Industry-standard Command Line
Interface (CLI).
08.0.01
08.0.01
08.0.01
08.0.01
08.0.01
08.0.01
08.0.10
NOTE
Configuration through web interface is not supported in this release. Only front panel display is
supported using Web.
NOTE
08.0.00a release supports 5 incoming telnet/SSH sessions and 5 outgoing telnet/SSH sessions.
Management port overview
NOTE
The management port applies to FCX, SX 800, SX 1600, ICX 6430, and ICX 6450 devices.
The management port is an out-of-band port that customers can use to manage their devices without
interfering with the in-band ports. The management port is widely used to download images and
configurations, for Telnet sessions.
For FCX devices, the MAC address for the management port is derived from the base MAC address of
the unit, plus the number of ports in the base module. For example, on a 48-port FCX standalone
device, the base MAC address is 0000.0034.2200. The management port MAC address for this device
would be 0000.0034.2200 plus 0x30, or 0000.0034.2230. The 0x30 in this case equals the 48 ports on
the base module.
