EZwarePlus Programming Manual 31
1010-1015, Rev. 03
4. Type “Bargraph” in the Name field. The number 11 should already be in the Window No. field.
5. Click the box for the Background color. The color palette box opens. Click on the white color box in the
lower-right corner. The color box will reflect the color that you have selected.
6. Click OK. Highlight Window 11: Bargraph in the Open Window list, then click the Open button. Window 11
now appears on your work area.
Now let’s create a function key to open Window 11 from the initial screen, Window 10.

To create a Function Key:
1. Click on Window 10 in the Windows Object List to open Window 10.
2. In the top menu bar in EZwarePlus, click Objects > Button > Function Key (or select the Function Key icon in
the Object 1 Toolbar).
3. In the Function Key Properties General tab, select Change full-screen window and select 11. Bargraph in the
Window no.: box.
4. Click the Shape tab and select the Use Shape checkbox. Click the Shape Library button to open the Shape
Library window. Click the Select Lib. button in the upper-right corner and browse to the arrow1.plb file and
click Open.
