Maple Systems 5000HD Series - Manual (Page 18)

12 EZwarePlus Programming Manual
1010-1015, Rev. 03
11. The new password must be entered, and then entered again to confirm. As the password is entered into the
confirm field, an indicator will show if the two passwords match.
12. Click on the History tab to display the History dialog. This is where data stored in the HMI can be cleared.
 This will not clear data stored on an SD card or USB flash drive.
Clear Recipe The HMI’s stored recipe data will be cleared when the Clear button is clicked.
Clear Eventlog The HMI’s stored event log data will be cleared when the Clear button is clicked.
Clear Datalog
The HMI’s stored data log data will be cleared when the Clear button is clicked.
13. Click on the HMI name tab to give the HMI a unique name. This name can be used to address the HMI for
downloading over Ethernet.
