236 EZwarePlus Programming Manual
1010-1015, Rev. 03
To begin monitoring data:
1. Select one or more monitor objects in the list (hold the shift key to select multiple objects) and click the Run
button in the toolbar. The status indicator for each selected monitor object will change from Stop to
Connected and the Value column will display a number or state.
If the red Address Error is displayed under the Status column, check the communication settings, address
syntax, and physical connection to the device.
To add a Macro object to the project:
1. Open the Macro Settings window by clicking on the Objects menu and selecting Add Object > Add Macro, or
by clicking on the Add New Macro icon in the toolbar.
2. Enter a name for the Macro object or use the default.
3. Select the HMI on which the macro resides.
