The HMI5000P/L/HD Series are powered using +24VDC. A reset switch is provided on the back of the HMI to
reinitialize the HMI if an operational failure occurs. The HMI5000P/L Series is designed for industrial environments
and carries a NEMA4/IP65 rating as well as CE compliance for noise immunity and emissions. The HMI5000HD series
carry the CE rating for noise and immunity, but are designed to be installed inside an enclosure.
List of Features
The next chapter will guide you through the creation of your first project. Before you proceed, you may wish to read
this brief list of some of the features offered in the EZwarePlus programming software.
Bit Lamp Creates a graphic object to reflect the current status of a PLC bit.
Word Lamp Creates a graphics object to reflect the current state of a multi-state PLC data
register.
Set Bit Creates a touchscreen graphics object that represents a two-state switch. When
pressed it sets/resets a PLC bit.
Set Word Creates a touchscreen graphic object that represents a multi-state switch. When
pressed it can place a constant value in a PLC register or jog the value.
Toggle Switch Creates a touchscreen graphic object that represents a two-state switch changing
state (picture) based upon a PLC bit. When pressed, it can control another PLC bit.
Multi-State
Switch Creates a multi-state touchscreen graphic object that changes state (picture)
according to the value in a PLC data register. When pressed, it sends a value(s) to
another PLC register.
Option List Displays a list of test items with the selected item being determined by the value in
a register. Optionally, selecting an item can write the corresponding value to a
register.
Slider Object Creates a touchscreen graphic object that changes the state according to the
position of a slider switch.
Function Key Creates a touchscreen graphic object that changes windows, inputs data as part of
a keypad, executes a macro, or prints the screen to a USB flash drive or printer.
Numeric Display Displays a number stored in a PLC register.
Numeric Input Displays a number stored in a PLC register. The number can be changed using a
numeric keypad.
ASCII Display Displays ASCII characters stored in a PLC register.
ASCII Input Displays ASCII characters stored in a PLC register. Characters can be changed using
an alphanumeric keypad.
Indirect Window Displays any Window based on the value in a PLC word address.
Direct Window Displays a specified Window based on a bit in a PLC register.
