EZwarePlus Programming Manual 255
1010-1015, Rev. 03
LW-10301 (16bit) : remote PLC 1's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-10302 (16bit) : remote PLC 1's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-10303 (16bit) : remote PLC 1's IP3 (IP address = IP0:IP1:IP2:IP3)
LW-10304 (16bit) : remote PLC 1's port no.
LW-10305 (16bit) : remote PLC 2's IP0 (IP address = IP0:IP1:IP2:IP3)
LW-10306 (16bit) : remote PLC 2's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-10307 (16bit) : remote PLC 2's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-10308 (16bit) : remote PLC 2's IP3 (IP address = IP0:IP1:IP2:IP3)
LW-10309 (16bit) : remote PLC 2's port no.
LW-10310 (16bit) : remote PLC 3's IP0 (IP address = IP0:IP1:IP2:IP3)
LW-10311 (16bit) : remote PLC 3's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-10312 (16bit) : remote PLC 3's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-10313 (16bit) : remote PLC 3's IP3 (IP address = IP0:IP1:IP2:IP3)
LW-10314 (16bit) : remote PLC 3's port no.
LW-10315 (16bit) : remote PLC 4's IP0 (IP address = IP0:IP1:IP2:IP3)
LW-10316 (16bit) : remote PLC 4's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-10317 (16bit) : remote PLC 4's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-10318 (16bit) : remote PLC 4's IP3 (IP address = IP0:IP1:IP2:IP3)
LW-10319 (16bit) : remote PLC 4's port no.
LW-10480 (16bit) : no. of event log files on SD card
LW-10481 (32bit) : size of event log files on SD card
LW-10483 (16bit) : no. of event log files on USB disk
LW-10484 (32bit) : size of event log files on USB disk
LW-10486 reserved
LW-10487 reserved
LW-10489 (16bit) : no. of data sampling files on SD card
LW-10490 (32bit) : size of data sampling files on SD card
LW-10492 (16bit) : no. of data sampling files on USB disk
LW-10493 (32bit) : size of data sampling files on USB disk
LW-10495 reserved
LW-10496 reserved
LW-10495 reserved
LW-10496 reserved
LW-10500 (16bit) : PLC 1 timeout (unit : 100ms)
LW-10501 (16bit) : PLC 1 turn around delay (unit : ms)
LW-10502 (16bit) : PLC 1 send ACK delay (unit : ms)
LW-10503 (16bit) : PLC 1 parameter 1
LW-10504 (16bit) : PLC 1 parameter 2
LW-10505 (16bit) : PLC 2 timeout (unit : 100ms)
LW-10506 (16bit) : PLC 2 turn around delay (unit : ms)
LW-10507 (16bit) : PLC 2 send ACK delay (unit : ms)
LW-10508 (16bit) : PLC 2 parameter 1
LW-10509 (16bit) : PLC 2 parameter 2
LW-10510 (16bit) : PLC 3 timeout (unit : 100ms)
LW-10511 (16bit) : PLC 3 turn around delay (unit : ms)
LW-10512 (16bit) : PLC 3 send ACK delay (unit : ms)
LW-10513 (16bit) : PLC 3 parameter 1
LW-10514 (16bit) : PLC 3 parameter 2
LW-10515 (16bit) : PLC 4 timeout (unit : 100ms)
