EZwarePlus Programming Manual 115
1010-1015, Rev. 03
The object can be configured to handle insufficient security in one of two ways:

The object can be hidden while security is not sufficient (Make invisible while protected).

The HMI can display the message defined as Message 1 in the System Message object
(Display warning message if access denied).
There are a number of local HMI addresses that can be used with the security features.
Address Description Data Type Notes
LB9050 Reset security level to 0 (no security) Boolean Set momentarily to trigger.
Also serves as user logout.
LB9060 Invalid password Boolean Set by the HMI when an invalid
password is entered. Must be
explicitly reset.
LB9061 Load new passwords Boolean Loads new passwords as defined by
LW9500-9523
LW9219 User level 16-bit unsigned Set to 1-12. Determines which
password is used.
LW9220 Password 32-bit unsigned Enter password into this address to
change the security level
