EZwarePlus Programming Manual 147
1010-1015, Rev. 03
System Message Windows
EZwarePlus has four Windows designated as System Message windows. Window #5 is designated as the PLC
Response Window that pops up automatically when the HMI loses communications with the PLC.
Window #6 is designated as the HMI Response window, which will pop up automatically with the HMI loses
communications with another HMI that is remotely connected.
Window #7 is designated as the Password Restriction Window, which will pop up when access is attempted on a
protected object without the proper password. The Display warning message if access denied checkbox must be
enabled in the Security tab > User restriction section of the object.
These windows have been pre-configured with automated messages and a function key to close the window, so no
changes are necessary, though you may customize them for your own application if desired.
Window #8 is designated as the Storage Space Insufficient Window, which will pop up when the available memory in
the HMI, USB Flash drive, or SD card is running low. The following Reserved Local Bits indicate insufficient memory
conditions:
LB9035 HMI free space insufficient alarm (when ON)
LB9036 SD Card free space insufficient alarm (when ON)
LB9037 USB free space insufficient alarm (when ON)
