Moving Shape Creates a multi-state graphic object, which changes state (picture) and position on
the screen according to a value in a PLC register.
Animation Creates a multi-state graphic object, which changes state (picture) on the screen
according to a value in a PLC register. The positions on the screen are predefined.
Media Player Displays a video file from a connected USB flash drive or SD card.
(HMI5121P and 5150P only)
Video In Input and play video on the HMI from an external source.
(HMI5121P and 5150P only)
Bar Graph Creates a bar graph with alarm monitoring.
Meter Display Creates a scale meter.
Trend Display Creates a trend graph. Monitors data in single or multiple PLC registers
and plots the data on a time graph.
History Data
Display Displays historical data in a tabular format.
Data Block
Display Displays the data stored in a series of registers as a line graph.
XY Plot Creates an XY Plot of data stored in a series of registers.
Recipe View Displays recipe data in a tabular format.
Alarm Bar Displays alarms detected by the Alarm (Event) Log Object on a single horizontal
scrolling line.
Alarm Display Display alarms detected by the Alarm (Event) Log Object in a table format.
Event Display Displays messages detected in the Alarm (Event) Log and can acknowledge the
message(s).
Alarm (Event)
Log Contains the data for detecting alarm conditions.
Data Transfer
(Trigger-based) Transfers data to the specified PLC registers based on a touch or PLC bit status.
Backup Copies recipe, event, or historical data to one of the USB flash drives or to a PC
connected via Ethernet.
Timer Controls an internal bit or PLC bit based on a timer; supports five different
configurations.
PLC Control Configures the HMI to monitor PLC data registers to display full window screens,
execute a data transfer, control the backlight, play a sound, execute a macro,
or print a screen.
