EZwarePlus Programming Manual 251
1010-1015, Rev. 03
LW-9552 (16bit) : COM 1 data bits (7 : 7 bits, 8 : 8 bits)
LW-9553 (16bit) : COM 1 parity (0:none, 1:even, 2:odd, 3:mark, 4:space)
LW-9554 (16bit) : COM 1 stop bits (1 : 1 bit, 2 : 2 bits)
LW-9555 (16bit) : COM 2 mode(0:RS232,1:RS485 2W,2:RS485 4W)
LW-9556 (16bit) : COM 2 baud rate(7:1200,8:2400,0:4800,1:9600,2:19200,3:38400,4:57600,..)
LW-9557 (16bit) : COM 2 data bits (7 : 7 bits, 8 : 8 bits)
LW-9558 (16bit) : COM 2 parity (0:none, 1:even, 2:odd, 3:mark, 4:space)
LW-9559 (16bit) : COM 2 stop bits (1 : 1 bit, 2 : 2 bits)
LW-9560 (16bit) : COM 3 mode(0:RS232,1:RS485 2W)
LW-9561 (16bit) : COM 3 baud rate(7:1200,8:2400,0:4800,1:9600,2:19200,3:38400,4:57600,..)
LW-9562 (16bit) : COM 3 data bits (7 : 7 bits, 8 : 8 bits)
LW-9563 (16bit) : COM 3 parity (0:none, 1:even, 2:odd, 3:mark, 4:space)
LW-9564 (16bit) : COM 3 stop bits (1 : 1 bit, 2 : 2 bits)
LW-9565 (16bit) : COM 1 broadcast station no.
LW-9566 (16bit) : COM 2 broadcast station no.
LW-9567 (16bit) : COM 3 broadcast station no.
LW-9570 (32bit) : received data count (bytes) (COM 1 MODBUS server)
LW-9572 (32bit) : received data count (bytes) (COM 2 MODBUS server)
LW-9574 (32bit) : received data count (bytes) (COM 3 MODBUS server)
LW-9576 (32bit) : received data count (bytes) (Ethernet MODBUS server)
LW-9600 (16bit) : PLC 4's IP0 (IP address = IP0:IP1:IP2:IP3)
LW-9601 (16bit) : PLC 4's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-9602 (16bit) : PLC 4's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-9603 (16bit) : PLC 4's IP3 (IP address = IP0:IP1:IP2:IP3)
LW-9604 (16bit) : PLC 4's port no.
LW-9605 (16bit) : PLC 5's IP0 (IP address = IP0:IP1:IP2:IP3)
LW-9606 (16bit) : PLC 5's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-9607 (16bit) : PLC 5's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-9608 (16bit) : PLC 5's IP3 (IP address = IP0:IP1:IP2:IP3)
LW-9609 (16bit) : PLC 5's port no.
LW-9610 (16bit) : PLC 6's IP0 (IP address = IP0:IP1:IP2:IP3)
LW-9611 (16bit) : PLC 6's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-9612 (16bit) : PLC 6's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-9613 (16bit) : PLC 6's IP3 (IP address = IP0:IP1:IP2:IP3)
LW-9614 (16bit) : PLC 6's port no.
LW-9615 (16bit) : PLC 7's IP0 (IP address = IP0:IP1:IP2:IP3)
LW-9616 (16bit) : PLC 7's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-9617 (16bit) : PLC 7's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-9618 (16bit) : PLC 7's IP3 (IP address = IP0:IP1:IP2:IP3)
LW-9619 (16bit) : PLC 7's port no.
LW-9620 (16bit) : PLC 8's IP0 (IP address = IP0:IP1:IP2:IP3)
LW-9621 (16bit) : PLC 8's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-9622 (16bit) : PLC 8's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-9623 (16bit) : PLC 8's IP3 (IP address = IP0:IP1:IP2:IP3)
LW-9624 (16bit) : PLC 8's port no.
LW-9625 (16bit) : PLC 9's IP0 (IP address = IP0:IP1:IP2:IP3)
LW-9626 (16bit) : PLC 9's IP1 (IP address = IP0:IP1:IP2:IP3)
LW-9627 (16bit) : PLC 9's IP2 (IP address = IP0:IP1:IP2:IP3)
LW-9628 (16bit) : PLC 9's IP3 (IP address = IP0:IP1:IP2:IP3)
