16 EZwarePlus Programming Manual
1010-1015, Rev. 03
Transferring Projects and Data from USB/SD Card
When a USB or SD device is inserted into the HMI5000P Series, a dialog is displayed. The same dialog is displayed for
transferring projects or data.
 Data is placed on the USB or SD device by EZwarePlus or Utility Manager.
Download Transfer data from the USB/SD to the HMI
Upload Transfer data from the HMI to the USB/SD
Restart Project and exit Close the dialog and restart the HMI
Cancel Close the dialog without transferring
Time Remaining The dialog will automatically close after 10 seconds if no selection
is made; shows the time remaining
When Download is selected, a dialog will appear requesting the Download password and what data to download.
