DS3134
83 of 203
Register Name: RHPL
Register Description: Receive HDLC Maximum Packet Length
Register Address:
0410h
7 6 5 4 3 2 1 0
RHPL7 RHPL6 RHPL5 RHPL4 RHPL3 RHPL2 RHPL1 RHPL0
15 14 13 12 11 10 9 8
RHPL15 RHPL14 RHPL13 RHPL12 RHPL11 RHPL10 RHPL9 RHPL8
Note: Bits that are underlined are read only, all other bits are read-write; default value for all bits is 0s.
This is a globe control only one per device and it is not one for each individual HDLC channel.
Bits 0 to 15 / Receive HDLC Packet Length (RHPL0 to RHPL15). If the Receive Length Detection
Enable bit is set to one, then the HDLC engine will check the number of received octets in a packet to see
if they exceed the count in this register. If the length is exceeded, then the packet is aborted and the
remainder is discarded. The definition of "octet length" is everything in between the opening and closing
flags which includes the address field, control field, information field, and FCS.
Register Name: THCDIS
Register Description: Transmit HDLC Channel Definition Indirect Select
Register Address:
0480h
7 6 5 4 3 2 1 0
HCID7 HCID6 HCID5 HCID4 HCID3 HCID2 HCID1 HCID0
15 14 13 12 11 10 9 8
IAB IARW n/a n/a n/a n/a n/a n/a
Note: Bits that are underlined are read only, all other bits are read-write; default value for all bits is 0.
Bits 0 to 7 / HDLC Channel ID (HCID0 to HCID7).
00000000 (00h) = HDLC Channel Number 1 (also used for the Fast HDLC Engine on Port 0)
00000001 (01h) = HDLC Channel Number 2 (also used for the Fast HDLC Engine on Port 1)
00000010 (02h) = HDLC Channel Number 3
11111111 (FFh) = HDLC Channel Number 256
Bit 14 / Indirect Access Read/Write (IARW). When the host wishes to read data from the internal
Transmit HDLC Definition RAM, this bit should be written to a one by the host. This causes the device
to begin obtaining the data from the channel location indicated by the HCID bits. During the read access,
the IAB bit will be set to one. Once the data is ready to be read from the THCD register, the IAB bit will
be set to zero. When the host wishes to write data to the internal Transmit HDLC Definition RAM, this
bit should be written to a zero by the host. This causes the device to take the data that is current present in
the THCD register and write it to the channel location indicated by the HCID bits. When the device has
completed the write, the IAB will be set to zero.
Bit 15 / Indirect Access Busy (IAB). When an indirect read or write access is in progress, this read only
bit will be set to a one. During a read operation, this bit will be set to a one until the data is ready to be
read. It will be set to zero when the data is ready to be read. During a write operation, this bit will be set
to a one while the write is taking place. It will be set to zero once the write operation has completed.
