DS3134
35 of 203
3.4 CHANNELIZED PORT REGISTERS (3XX)
Offset/
Address Acronym Register Name Section
0300 CP0RDIS Channelized Port 0 Register Data Indirect Select. 5.3
0304 CP0RD Channelized Port 0 Register Data. 5.3
0308 CP1RDIS Channelized Port 1 Register Data Indirect Select. 5.3
030C CP1RD Channelized Port 1 Register Data. 5.3
0310 CP2RDIS Channelized Port 2 Register Data Indirect Select. 5.3
0314 CP2RD Channelized Port 2 Register Data. 5.3
0318 CP3RDIS Channelized Port 3 Register Data Indirect Select. 5.3
031C CP3RD Channelized Port 3 Register Data. 5.3
0320 CP4RDIS Channelized Port 4 Register Data Indirect Select. 5.3
0324 CP4RD Channelized Port 4 Register Data. 5.3
0328 CP5RDIS Channelized Port 5 Register Data Indirect Select. 5.3
032C CP5RD Channelized Port 5 Register Data. 5.3
0330 CP6RDIS Channelized Port 6 Register Data Indirect Select. 5.3
0334 CP6RD Channelized Port 6 Register Data. 5.3
0338 CP7RDIS Channelized Port 7 Register Data Indirect Select. 5.3
033C CP7RD Channelized Port 7 Register Data. 5.3
0340 CP8RDIS Channelized Port 8 Register Data Indirect Select. 5.3
0344 CP8RD Channelized Port 8 Register Data. 5.3
0348 CP9RDIS Channelized Port 9 Register Data Indirect Select. 5.3
034C CP9RD Channelized Port 9 Register Data. 5.3
0350 CP10RDIS Channelized Port 10 Register Data Indirect Select. 5.3
0354 CP10RD Channelized Port 10 Register Data. 5.3
0358 CP11RDIS Channelized Port 11 Register Data Indirect Select. 5.3
035C CP11RD Channelized Port 11 Register Data. 5.3
0360 CP12RDIS Channelized Port 12 Register Data Indirect Select. 5.3
0364 CP12RD Channelized Port 12 Register Data. 5.3
0368 CP13RDIS Channelized Port 13 Register Data Indirect Select. 5.3
036C CP13RD Channelized Port 13 Register Data. 5.3
0370 CP14RDIS Channelized Port 14 Register Data Indirect Select. 5.3
0374 CP14RD Channelized Port 14 Register Data. 5.3
0378 CP15RDIS Channelized Port 15 Register Data Indirect Select. 5.3
037C CP15RD Channelized Port 15 Register Data. 5.3
3.5 HDLC REGISTERS (4XX)
Offset/
Address Acronym Register Name Section
0400 RHCDIS Receive HDLC Channel Definition Indirect Select. 6.2
0404 RHCD Receive HDLC Channel Definition. 6.2
0410 RHPL Receive HDLC maximum Packet Length. One per Device 6.2
0480 THCDIS Transmit HDLC Channel Definition Indirect Select. 6.2
0484 THCD Transmit HDLC Channel Definition. 6.2
