DS3134

144 of 203

Bits 8 to 11 / Transmit DMA Configuration RAM Word Select Bits 0 to 3 (TDCW0 to TDCW3).

0000 = lower word of dword 0
0001 = upper word of dword 0
0010 = lower word of dword 1 (only word that the Host can write to)
0011 = upper word of dword 1
0100 = lower word of dword 2
0101 = upper word of dword 2
0110 = lower word of dword 3
0111 = upper word of dword 3
1000 = lower word of dword 4
1001 = upper word of dword 4
1010 = lower word of dword 5
1011 = upper word of dword 5

Bit 14 / Indirect Access Read/Write (IARW). When the host wishes to read data from the internal
Transmit DMA Configuration RAM, this bit should be written to a one by the host. This causes the
device to begin obtaining the data from the channel location indicated by the HCID bits. During the read
access, the IAB bit will be set to one. Once the data is ready to be read from the TDMAC register, the
IAB bit will be set to zero. When the host wishes to write data to the internal Transmit DMA
Configuration RAM, this bit should be written to a zero by the host. This causes the device to take the
data that is current present in the TDMAC register and write it to the channel location indicated by the
HCID bits. When the device has completed the write, the IAB bit will be set to zero.

Bit 15 / Indirect Access Busy (IAB). When an indirect read or write access is in progress, this read only
bit will be set to a one. During a read operation, this bit will be set to a one until the data is ready to be
read. It will be set to zero when the data is ready to be read. During a write operation, this bit will be set
to a one while the write is taking place. It will be set to zero once the write operation has completed.

TDMAC

0874h

D15

D14

D13

D12

D11

D10

Note: Bits that are underlined are read only, all other bits are read-write.

Bits 0 to 15 / Transmit DMA Configuration RAM Data (D0 to D15). Data that is written to or read
from the Transmit DMA Configuration RAM.
