DS3134

38 of 203

3.11 PCI CONFIGURATION REGISTERS FOR FUNCTION 1 (PIDSEL/BXX)

Offset/
Address

Acronym

Register Name

Section

0x100/0B00

PVID1

PCI Vendor ID / Device ID 1.

9.2

0x104/0B04

PCMD1

PCI Command Status 1.

9.2

0x108/0B08

PRCC1

PCI Revision ID / Class Code 1.

9.2

0x10C/0B0C

PLTH1

PCI Cache Line Size / Latency Timer / Header Type 1.

9.2

0x110/0B10

PLBM

PCI Device Local Base Memory Base Address.

9.2

0x13C/0B3C

PINTL1

PCI Interrupt Line & Pin / Min. Grant / Max. Latency 1.

9.2
