DS3134
71 of 203
5.6 BERT REGISTER DESCRIPTION
BERT Register Set Figure 5.6A
BERTC0: BERT Control 0 lsb
n/a TINV RINV PS2 PS1 PS0 LC RESYNC
msb
IESYNC IEBED IEOF n/a RPL3 RPL2 RPL1 RPL0
BERTC1: BERT Control 1 lsb
EIB2 EIB1 EIB0 SBE n/a n/a n/a TC
msb
Alternating Word Count
BERTRP0: BERT Repetitive Pattern Set 0 (lower word) lsb
BERT Repetitive Pattern Set (lower byte)
msb
BERT Repetitive Pattern Set
BERTRP1: BERT Repetitive Pattern Set 1 (upper word) lsb
BERT Repetitive Pattern Set
msb
BERT Repetitive Pattern Set (upper byte)
BERTBC0: BERT Bit Counter 0 (lower word) lsb
BERT 32-Bit Bit Counter (lower byte)
msb
BERT 32-Bit Bit Counter
BERTBC1: BERT Bit Counter 0 (upper word) lsb
BERT 32-Bit Bit Counter
msb
BERT 32-Bit Bit Counter (upper byte)
BERTEC0: BERT Error Counter 0 / Status lsb
n/a RA1 RA0 RLOS BED BBCO BECO SYNC
msb
BERT 24-Bit Error Counter (lower byte)
BERTEC1: BERT Error Counter 1 (upper word) lsb
BERT 24-Bit Error Counter
msb
BERT 24-Bit Error Counter (upper byte)
