DS3134
21 of 203
Lead
Symbol
Type
Signal Description
E4
TS0
I
Transmit Serial Sync for Port 0.
F3
TS1
I
Transmit Serial Sync for Port 1.
G1
TS2
I
Transmit Serial Sync for Port 2.
J2
TS3
I
Transmit Serial Sync for Port 3.
N2
TS4
I
Transmit Serial Sync for Port 4.
R2
TS5
I
Transmit Serial Sync for Port 5.
T3
TS6
I
Transmit Serial Sync for Port 6.
W1
TS7
I
Transmit Serial Sync for Port 7.
A17
TS8
I
Transmit Serial Sync for Port 8.
B15
TS9
I
Transmit Serial Sync for Port 9.
B13
TS10
I
Transmit Serial Sync for Port 10.
B11
TS11
I
Transmit Serial Sync for Port 11.
B9
TS12
I
Transmit Serial Sync for Port 12.
A6
TS13
I
Transmit Serial Sync for Port 13.
B5
TS14
I
Transmit Serial Sync for Port 14.
C4
TS15
I
Transmit Serial Sync for Port 15.
D6
VDD
-
Positive Supply. 3.3V (+/- 10%).
D10
VDD
-
Positive Supply. 3.3V (+/- 10%).
D11
VDD
-
Positive Supply. 3.3V (+/- 10%).
D15
VDD
-
Positive Supply. 3.3V (+/- 10%).
F4
VDD
-
Positive Supply. 3.3V (+/- 10%).
F17
VDD
-
Positive Supply. 3.3V (+/- 10%).
K4
VDD
-
Positive Supply. 3.3V (+/- 10%).
K17
VDD
-
Positive Supply. 3.3V (+/- 10%).
L4
VDD
-
Positive Supply. 3.3V (+/- 10%).
L17
VDD
-
Positive Supply. 3.3V (+/- 10%).
R4
VDD
-
Positive Supply. 3.3V (+/- 10%).
R17
VDD
-
Positive Supply. 3.3V (+/- 10%).
U6
VDD
-
Positive Supply. 3.3V (+/- 10%).
U10
VDD
-
Positive Supply. 3.3V (+/- 10%).
U11
VDD
-
Positive Supply. 3.3V (+/- 10%).
U15
VDD
-
Positive Supply. 3.3V (+/- 10%).
A1
VSS
-
Ground Reference.
D4
VSS
-
Ground Reference.
D8
VSS
-
Ground Reference.
D9
VSS
-
Ground Reference.
D13
VSS
-
Ground Reference.
D17
VSS
-
Ground Reference.
H4
VSS
-
Ground Reference.
H17
VSS
-
Ground Reference.
J17
VSS
-
Ground Reference.
M4
VSS
-
Ground Reference.
N4
VSS
-
Ground Reference.
N17
VSS
-
Ground Reference.
U4
VSS
-
Ground Reference.
