Bit Symbol Lead I/O Control Bit Description
80 RD5 R1 I
79 TC5 P3 I
78 TS5 R2 I
77 TD5 T1 O
76 RC6 P4 I
75 RS6 R3 I
74 RD6 T2 I
73 TC6 U1 I
72 TS6 T3 I
71 TD6 U2 O
70 RC7 V1 I
69 RS7 T4 I
68 RD7 U3 I
67 TC7 V2 I
66 TS7 W1 I
65 TD7 V3 O
64 PRST* W3 I
63 PCLK Y2 I
62 PGNT* W4 I
61 PREQ* V4 O
60 PAD.iocntl - - 0 = PAD0 to PAD31 are inputs;PAD0 to PAD31 are
outputs
59 PAD31 U5 I/O
58 PAD30 Y3 I/O
57 PAD29 Y4 I/O
56 PAD28 V5 I/O
55 PAD27 W5 I/O
54 PAD26 Y5 I/O
53 PAD25 V6 I/O
52 PAD24 U7 I/O
51 PCBE3.iocntl - - 0 = PCBE3* is an input; 1 = PCBE3* is an output
50 PCBE3* W6
49 PIDSEL Y6 I
48 PAD23 V7 I/O
47 PAD22 W7 I/O
46 PAD21 Y7 I/O
45 PAD20 V8 I/O
44 PAD19 W8 I/O
43 PAD18 Y8 I/O
42 PAD17 U9 I/O
41 PAD16 V9 I/O
40 PCBE2.iocntl - - 0 = PCBE2* is an input; 1 = PCBE2* is an output
39 PCBE2* Y9 I/O
38 PFRAME.iocntl - - 0 = PFRAME* is an input; 1 = PFRAME* is an output
37 PFRAME* W10 I/O
