Horizontal Res. (HD)
Description Number of white-to-black and black-to-white transitions that
can be seen from the left to the right of the picture (pixels).
The setting value depends on the selected video standard.
Values For detailed information on horizontal resolution for each video
standard and codec, see section "Codec-Related Information"
on page 56.
Recorded Lines (SD)
Description Number of lines recorded from the left to the right of the picture.
The setting value depends on the selected video standard.
Values For detailed information on recorded lines for each video
standard and codec, see section "Codec-Related Information"
on page 56.
LTC Timecode
Description Longitudinal timecode (timecode information stored on a
separate track from the video) delivered to the EVS server, and
timecode status.
Values The timecode is given as hh:mm:ss:fr
The timecode status can be 'OK', 'BAD', 'LOST' or 'DRIFT'
(defined by the EVS server).
Sync PC Time to TC
Description Specifies whether the PC time is synchronized with the
timecode, and how often the synchronization takes place.
Values Synchronization: 'Yes', 'No'
Frequency: by default 'every 00h15' (not editable)
Genlock
Description Specifies the type of genlock signal, the status and the frame
synchronizer mode.
Values Type: 'Blackburst' or 'Tri-Sync' (always 'Blackburst' in SD)
Status: 'OK' or 'BAD' (defined by the EVS server)
Mode: 'Studio' (no correction of a shifted video signal) or
'Resync' (resynchronization of a shifted video signal)
XT3 Server - Version 11.00 - Configuration Manual
3. Multicam Configuration 54
