2.2.4.

Renaming Configuration Lines

Introduction

When the EVS server is delivered, default names are assigned to the configuration lines.
You can change them as explained below.

In the Server-Based Application

To rename the configuration line in the server-based application, proceed as follows:

1. Press the UP ARROW or DOWN ARROW key to respectively move up and down in

the list of configuration lines until the requested line is highlighted.

2. Press CTRL+F1.

The line if highlighted in pink and the cursor blinks on the first character.

3. Type the new name for the configuration line taking the following into account:

The space bar allows you to delete the selected character.

The LEFT ARROW and RIGHT ARROW keys allow you to move the cursor
position on the line.

4. Press ENTER to validate the new name.

The new name is assigned to the configuration line and reflected in all user interfaces.

In the Web-Based Interface

To rename the configuration line in the web-based interface, proceed as follows:

1. Click the Rename button

next to the configuration line you want to rename.

2. In the Rename dialog box, type the new configuration name.
3. Click OK.

The new name is assigned to the configuration line and reflected in all user interfaces.

2.2.5.

Exporting and Importing Configuration Lines

How to Export Configuration Lines

In the Server-Based Application

Note
In the server-based application, the configuration lines are exported onto a USB
key. For this reason, you first need to insert a USB key on the USB port located
on the front panel of the EVS server.

To export configuration lines from an EVS server in the server-based application, proceed
as follows:

XT3 Server - Version 11.00 - Configuration Manual

2. Multicam Setup

14
