EVS XT3 Version 11.00 Configuration Manual - Manual (Page 30)

How to Deactivate the Password on the EVS Server
Once the password protection is active, it can only be deactivated from the server-based
application as follows:
1. In the Multicam Setup window, press W to call the Enable password command.
A message opens to warn you that you are about to remove the password protection:
2. Press the RIGHT ARROW key to select 'Yes' and press ENTER
3. Type the password in the dialog box that opens, and press ENTER to validate:
The password protection is directly removed from all user interfaces.
2.3.4. Setting the Server LAN PC Address
Introduction
The MTPC board of an EVS server allows interaction with other EVS hardware on a setup
via the LAN PC address. The port #1 of the MTPC board is used. The communication is
established through telnet or FTP access. XNet Monitor will also use the LAN IP
connection to transfer the monitoring data.
Note
You can only define the settings associated with the LAN PC address from
the server-based application.
Settings
The MTPC board connection settings are described in the table below:
Setting Description
IP Address Specifies the IP address to connect to the port #1 of the MTPC board on
the server. The IP addresses 0.0.0.0 and 255.255.255.255 are not
allowed.
Subnet Mask Specifies the range of logical addresses within the address space
assigned to the MTPC board connection.
Default
Gateway Specifies the IP address of the router on the network that the MTPC
board can use as an access point to external networks.
XT3 Server - Version 11.00 - Configuration Manual
2. Multicam Setup 24
