PGM Speed / var max

Context

During playback, if PGM Speed or Var Max has been enabled
in the secondary menu of the LSM Remote Panel, the lever
range will be adapted so that:

the only playback value for any position of the lever other
than 0, is the one specified by this parameter in the setup
(PGM Spd mode ON)
OR

the speed range defined by the lever is limited to the value
specified by this parameter (VarMax mode ON).

Description

Specifies the playback speed assigned to the lever when the
PGM Speed or Var Max commands are used.

Values

Range of values from 1 to 400 %

Default value

50%

Lever engage mode

Description

Specifies how the playback speed varies depending on the
position of the lever.

Values

The following values are possible:

Direct mode:
The lever will engage directly when moved, resulting in a
speed jump to the desired speed determined by the lever
arm position.

Current speed mode:
The lever will only engage when it reaches the current
playback speed, whereas a move of the lever arm in the
opposite direction of the current speed will result in a direct
speed change.

Default value

Direct
