3. Multicam Configuration
3.1. Overview on User Interfaces
3.1.1. Introduction
Preliminary Remarks
Configuration as Initial Step
Prior to using Multicam, the operator should set all necessary parameters in the Multicam
Configuration window. If clips are stored with certain parameters and the operator wishes
to change the parameter values afterwards, those clips and playlists will not change.
Configuration with Caution
Most parameters are factory preset, and should not be modified without advice of qualified
EVS staff. Improper values for some parameters will prevent the proper operation of the
system.
Parameter Availability
Only the parameters or parameter values valid for the given server type, server chassis,
and active license codes are available for the definition of the various configurations.
General Comparison Between User Interfaces
You can configure the EVS server using one of the three available user interfaces:
• Multicam Configuration window in the server-based application
• Multicam Configuration window in the web-based interface
• Technical and Operational Setup menus in the Remote Panel
The Multicam Configuration windows in the server-based and web-based interface are
almost identical.
In the Remote Panel, however, only the most used technical settings are available in the
Technical Setup menu, and all operational settings are available in the Operational Setup
menu.
The following table provides an overview on the features available in each user interface:
Configuration Window
Technical Settings Operational Settings
Server-Based
Application Yes
(tabs 1-6)
Yes
(tab 7)
web-based
interface Yes
(tabs 1-6)
Yes
(tab 7)
Remote Panel Yes (partly)
(Technical Setup: F0)
Yes
(Setup Menu: SHIFT+D)
