Cam X
Availability This setting is displayed for each available camera line that
can be mapped to a network camera.
Description Specifies the network camera mapped to the corresponding
local camera.
Values The available network camera that can be mapped.
Default Values none
3.8.13. Hypermotion Management
Principles
The hypermotion cameras can be controlled by the LSM Remote Panel. The camera is
linked via a RS422 or LAN PC connector to the same XT3 server as the controlling
Remote Panel.
In setups including a hypermotion camera, the following principles apply:
• An XT3 server cannot control more than one hypermotion camera.
• The hypermotion camera is used with the classical channel configurations.
• Not all Multicam LSM configurations with several PGMs and several Remotes are
supported within the current RS422 and channel configuration constraints.
• If the Remote Mode setting in the Hypermotion Controller settings is set to
‘Hypermotion only’, an additional menu is made available in the main menu of the LSM
Remote Panel.
Remote Panel Assignment
In setups where several LSM Remote Panels and a hypermotion camera are defined, the
assignment of the various PGMs and hypermotion camera to the LSM Remote Panels is
automatically performed as shown in the table below depending on:
• the number of PGMs in the selected channel configuration
• the selected Remote Mode (Hypermotion only or Hypermotion + LSM)
• the number of Remote Panels available
The following table presents the possible configurations:
