2.3.7. Configuring Server Raids
Introduction
When the EVS server is started, the server raids are automatically detected, and built
based on the default settings described in the 'Default Raid Configuration' section below.
You can view the default raid configuration and modify it from the Raid Configuration
window. This window is only available in the server-based application.
Note
Only SAS drives from EVS can be used as they are specifically configured to
work with EVS video servers.
Overview on the Raid Configuration Window
The Raid Configuration window is available from the Multicam Setup window, when
pressing R to call the Raid Configuration command in the Tools menu:
The Requested Configuration area, in the upper part of the window, displays the default
raid configuration. You can modify the default raid configuration in this area. You will find
more information on editable parameters below.
The Current Configuration area, in the lower part of the Raid Configuration window,
provides raid and disk status information..
Default Raid Configuration
At the first start, the software builds the raids using the following settings:
• If internal and external storage are detected, both are used.
• (5+1) raid configuration with a maximum of 5 spares is used. First, all the raids are
built. The remaining disks are used as spare disks. The construction of raids starts
with internal arrays and carries on with external arrays. A raid can be created across
several hardware arrays.
