Remote mode
Description Specifies the camera elements controlled by the server.
Values • Hypermotion only:
The server controls only the hypermotion camera. An
additional remote is made available in the main menu of
the remote panel, since the hypermotion camera is
considered as an additional external camera.
• Hypermotion + LSM:
The server controls the hypermotion camera and one PGM
in exclusive mode.
Default value Hypermotion only
Port
Description Specifies on which port (RS422 or Lan PC) the commands
must be sent to the hypermotion camera, and possibly to the
PGM if you have selected ‘Hypermotion + LSM” in the
Remote Mode parameter.
Values The following values are possible:
• RS422 #2 to RS422 #6
• Lan PC
Default value RS422 #6
Protocol
Description Specifies the protocol type used for data transfer on the
selected port.
Values The following values are possible:
• TCP / UDP (when Port is set to Lan PC).
• ASCII / Sony 9-pin (when Port is set to one of the RS422).
Default values • TCP (when Port is set to Lan PC).
• Sony 9-pin (when Port is set to one of the RS422).
IP Address
Availability This setting is only available if the Port setting is set to Lan
PC.
Description Specifies the IP address of the PC LAN.
Values xxx.xxx.xxx.xxx
Default value 192.168.10.60
XT3 Server - Version 11.00 - Configuration Manual
3. Multicam Configuration 214
