Setting Name Basic Advanced
Technical
Setup
User TC of created clips – X T5.4 / T5.7
OSD Settings P2 / P3 P2 / P3 T5.4 to T5.5 /
T5.7 to T5.8
OSD on Output X X T5.4 / T5.7
Display sel – X T5.4 / T5.7
TC H-Pos – X T5.5 / T5.8
TC V-Pos – X T5.5 / T5.8
Name H-Pos – X T5.5 / T5.8
Name V-Pos – X T5.5 / T5.8
Audio Settings P2 / P3 P2 / P3 T5.3 / T5.6
Edit audio Fade X X X
Channel Settings P2 / P3 P2 / P3 T5.4 / T5.7
EE X X X
Stop Behavior X X X
RS422 VarID Settings – P4 –
Uniqueness – read only –
Length – read only –
Format – read only –
VDCP visibility Settings – P4 –
Port #1...6 – read only –
3.6.2. RS422 Protocols Settings
Introduction
The RS422 Protocols settings allow specifying the settings related to the clip
identification used to access the video clips.
These fields are available in the following interfaces:
• in the Multicam Configuration window, Protocol tab, on page 1 in the basic and
advanced display mode in the server- and web-based interfaces.
