Requested Raid Configuration
Overview
In the Requested Raid Configuration, you can modify the following parameters in the
default raid configuration:
• Use of internal and/or external storage.
• Use of spare disks.
• Number of raids to be used.
To modify one of these parameters, press TAB to select the requested field, and
SPACE BAR to select the requested value, or type the requested value.
Field Description
The following table describes the fields editable in the Requested Configuration area in the
Raid Configuration window. The fields are described in the sequence they are highlighted
when using the TAB key.
Field Name Description
Storage type Specifies which storage type you will use. When both
storage types are available, the following values are
possible:
• Internal only
• External + Internal
• External only
Number of raids Specifies the number of raids you want to use.
Type the number of raids you want to use.
Raid configuration
type Specifies the raid configuration type.
The software is able to handle two raid organizations:
• (4+1): raid of 5 disks
• (5+1): raid of 6 disks
Current Raid Configuration
This area is used to display the raid status for the selected configuration when the EVS
server is running a configuration.
