Resolution
Description Vertical resolution used (number of white-to-black and black-
to-white transitions that can be seen from the top to the bottom
of the picture) (pixel + type).
Both field rate and resolution correspond to the video standard.
With an XT3 server, SD and HD video standards can be
available if the relevant license codes are activated.
Values In SD:
• 525i
• 625i
In HD:
• 720p
• 1080i
• 1080p (only available with code 21 or 22)
Codec
Description Algorithm used to compress and decompress the video signal.
The codecs available on the EVS server depend on the video
standard used, as well as on the active license codes.
For detailed information on codec availability, see section
"Codec Availability" on page 55.
Values In SD:
• Proxy (Jpeg)
• Mjpeg (SD)
• IMX
• DVCPro 50
In HD:
• Mjpeg EVS (HD)
• Mjpeg Standard (HD)
• Mpeg 2 Intra (HD)
• Avid DNxHD 120, 185 or 185x (only in 50 Hz)
• Avid DNxHD 145, 220 or 220x (only in 59.94 Hz)
• Apple ProRes 422, 422 LT, 422 HQ or 422 HQ (10-bit)
• DVCPro HD
• AVC-Intra 100
Default values • IMX in SD
• Avid DNxHD 120 in HD 50Hz
• Avid DNxHD 145 in HD 59.94 Hz
Bitrate
Description Number of megabits processed per second (Mbps).
The bitrate depends on the codec.
Values For detailed information on bitrates per codec, see section
"Codec-Related Information" on page 56.
