Example: 1SLSM 2PH + 2PLAY

The BNC connectors to be used as record and play channels in an SLSM configuration
with 1SLSM 2PH + 2 PLAY need to be cabled as shown below:

Available SLSM 3x Configurations

The table below shows the available SLSM 3 Phase configurations in SD/HD with a XT3
4U server, and how the BNC connectors should be cabled:

IN4/OUT3

IN3/OUT4

IN2/OUT5

IN1/OUT6

#REC
SLSM
3x

#REC

#PLAY

Prim.
Link

Sec.
Link

Prim.
Link

Sec.
Link

Prim.
Link

Sec.
Link

Prim.
Link

Sec.
Link

1

0

0

REC1,3

REC1,2

REC1,1

1

1

0

REC2

REC1,3

REC1,2

REC1,1

1

0

1

PLAY1

MIX1

REC1,3

REC1,2

REC1,1

XT3 6UServers

Available SLSM 2x Configurations

The table below shows the available SLSM 2 Phase configurations in SD/HD with a XT3
6U server, and how the BNC connectors should be cabled:

97

3. Multicam Configuration

EVS Broadcast Equipment S.A. - April 2012

Issue 11.00.C
