Char OUT J4
Description Specifies the monitoring output type generated on the J4
connector.
Values • SD
• HD
Default value System dependent
Char OUT J1
Description Specifies the monitoring output type generated on the J1
connector.
Values • CVBS
• SDI
Default value CVBS
OUT B J3
Description Specifies the output type generated on the J3 connector.
Values • SD
• HD
Default value System dependent
Aspect ratio
Warning
A change to this parameter requires an application reboot (ALT+Q from the
operational windows) to be taken into account.
Description Defines the frame ratio.
Values • 4:3 L Box
• 4:4 crop
• 16:9
Default value 4:3 L Box
149 3. Multicam Configuration
