OSD Settings for Edit Rec
Introduction
The OSD settings allow specifying the settings related to the OSD and information to be
displayed on the monitoring screen.
These fields are available in the following interfaces:
• in the Multicam Configuration window, Protocol tab, on page 2 for Edit Rec 1 and on
page 3 for Edit Rec 2, in the basic and advanced display mode in the server- and web-
based interfaces (some parameters are only available in the advanced mode).
• in the Technical menu of the Remote Control Panel, pages T5.4-5 for Edit Rec 1 and
on page T5.7-8 for Edit Rec 2.
The following screenshot presents page 2 in advanced mode of the Protocol tab in the
server-based application and highlights the OSD settings area.
OSD on Output
Description Activates or deactivates the OSD feature.
Values Yes / No
Default value Yes
