Grab image
Availability This setting is only available if the license code 177 is valid.
Description Enables / disables an image grab when the MARK key on the
LSM Remote Panel is hit, and when a default XFile has been
assigned.
Each time the MARK key is used, a cue point is marked and a
command is sent to the XFile to save that image.
The grab can also be activated on the keyboard with the
combination CTRL + G.
Values Yes / No
Default value No
Browse button
Description Allows users to convert the function of the BROWSE key.
Values The following values are possible:
• Browse:
This will directly activate the playlist browse function,
which is the default function assigned to this key.
• Sort TC:
The system will perform a Sort TC directly. The system
will not prompt the user with a select menu, and it will use
the current TC on the channel to search with the last
selected criteria.
If the user wants to perform a search with different criteria
(Search Net or Local, StartDate, EndDate, CAM/CLIP,
etc… ), the user should use the normal Sort-TC selection
in the upper menu..
Default value Browse
3.8.12. Cam Mapping Settings
Introduction
The Cam Mapping settings allow specifying the settings related to the mapping of
network cameras to unused camera positions on the remote up to the camera D.
These fields are available in the following interfaces:
• in the Multicam Configuration window, Operation tab, in the basic display mode:
◦
on page 5 on the server-based application.
◦ on page 1 on the web-based interface.
• in the Operational setup menu of the Remote Control Panel (page 10.1).
