Audio Embedded Outputs
By default, the audio mono channels from the A/V material stored on the EVS server are
mapped to the embedded mono channels on the player channels as presented in the table
below.
The table shows the maximum number of players, and an audio configuration with 16
tracks (mono channels):
OUT 1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6
Mono1 E1-01 E2-01 E3-01 E4-01 E5-01 E6-01
Mono2 E1-02 E2-02 E3-02 E4-02 E5-02 E6-02
Mono3 E1-03 E2-03 E3-03 E4-03 E5-03 E6-03
Mono4 E1-04 E2-04 E3-04 E4-04 E5-04 E6-04
Mono5 E1-05 E2-05 E3-05 E4-05 E5-05 E6-05
Mono6 E1-06 E2-06 E3-06 E4-06 E5-06 E6-06
Mono7 E1-07 E2-07 E3-07 E4-07 E5-07 E6-07
Mono8 E1-08 E2-08 E3-08 E4-08 E5-08 E6-08
Mono9 E1-09 E2-09 E3-09 E4-09 E5-09 E6-09
Mono10 E1-10 E2-10 E3-10 E4-10 E5-10 E6-10
Mono11 E1-11 E2-11 E3-11 E4-11 E5-11 E6-11
Mono12 E1-12 E2-12 E3-12 E4-12 E5-12 E6-12
Mono13 E1-13 E2-13 E3-13 E4-13 E5-13 E6-13
Mono14 E1-14 E2-14 E3-14 E4-14 E5-14 E6-14
Mono15 E1-15 E2-15 E3-15 E4-15 E5-15 E6-15
Mono16 E1-16 E2-16 E3-16 E4-16 E5-16 E6-16
Audio Digital Outputs
The default mapping to audio digital output connectors differ depending on the number of
tracks (mono channels) defined.
8 Audio Tracks
With audio configurations with 4 or 16 tracks (mono channels), the audio mono channels
of the A/V material stored on the EVS server are sent to the digital audio output
connectors of the player channels as presented in the table below.
