Note
• For all protocols, except AVSP, use the channel assignment (PGM1 to
PGM6) instead of the device protocol type (Sony BVW75, Odetics).
• The AVSP protocol does not require any GPI IN setting in the setup menu
as they are defined through specific serial AVSP commands.
TTL GPIs set as GPIs
Description Defines the 4 configurable GPIs as inputs or outputs.
Values In / Out
Default value In
GPIs IN - Channel/Device
Description Specifies the server channel or the external device connected
to the corresponding GPI input line, and therefore to which
channel or device the GPI will be sent to.
Values The following values are possible and correspond to one of the
channels or controllers assigned in the Channel and Control
settings (Channels tab, page 1):
• PGMx: The GPI is sent to the specified play channel.
• RECx: The GPI is sent to the specified record channel.
• RMTx: The GPI is sent to the remote controller.
• : The GPI is sent to the third-party
controlling device.
GPIs IN - Port
Description Specifies the RS422 port on which the server will receive the
input signal. This setting is relevant when the device is an
EVS remote controller or third-party controller.
Values The possible values are from 1 to 6: it corresponds to the
RS422 port to which the controller specified in the
Channel/Device field is assigned in the Port settings
(Channels tab, page 1).
169 3. Multicam Configuration
EVS Broadcast Equipment S.A. - April 2012 Issue 11.00.C
