Pointing device

Description

Specifies the pointing device connected to the EVS server,
and initializes it.
If the tablet is not properly calibrated, this function will re-
initialize it.
If you use the touch screen, it must always be connected to
RS422 port #6 of the server, and defined as such in the
Channels tab, Port settings.

Values

Tablet / Touch Screen

Default value

Tablet

VGA & Remote sync

Description

Specifies whether and how the current clips machine, page
and bank of VGA screens and LSM Remote Panel must be
synchronized.

Values

The following values are possible:

No:
Clip machine, page and bank can be selected
independently on the VGA screen and on the LSM Remote
Panel.

Yes:
Clip machine, page and bank are synchronized between
VGA screen and LSM Remote Panel. Connecting to the
clips of a network machine or coming back to the clips of
the local machine, or selecting a new page or bank on one
side will be automatically reflected on the other.

Server:
Clip pages and banks can be selected independently on
VGA and LSM Remote Panel, but connecting to the clips
of a network machine or coming back to the clips of the
local machine on the VGA or Remote Panel will be
automatically reflected on the other.

Default value

No

Call channel VGA

Description

Enables or disables the Call Channel function on the VGA
Clip screen. This function allows the operator to select on
which PGM channel the clips called from the keyboard/tablet
and VGA should be loaded.

Values

Yes / No

Default value

Yes

207

3. Multicam Configuration

EVS Broadcast Equipment S.A. - April 2012

Issue 11.00.C
