Use guardband
Description Makes the OUT guardband available to the protocol.
Values • Yes, meaning that the protocol has access to the IN and
OUT guardbands.
• No, meaning that the protocol has only access to the IN
guardband.
Default value No
List Remote CAM
Description Allows access to the CAM recorders of the remote server
specified in the XNet field.
Values • Yes, meaning that the recorders of the local server and the
remote server are available.
• No, meaning that only the recorders of the local server are
available.
Default value No
SONY Parallel Status
Description Activates the Sony serial connection status reporting when
several controllers are used in parallel mode.
Values Yes / No
Default value Yes
3.6.5. RS422 VarID Settings
Introduction
The RS422 VarID settings and the VDCP visibility settings display the VarID settings
that are applicable to the VDCP protocol.
These fields are available in the following interfaces:
• in the Multicam Configuration window, Protocol tab, on page 4 in the advanced display
mode in the server- and web-based interfaces.
The following screenshot presents page 4 in advanced mode of the Protocol tab in the
server-based application and highlights the RS422 VarID and the VDCP visibility settings
areas.
