3.5. Monitoring Tab
3.5.1. Overview
Monitoring Tab
The Monitoring tab consists of one page in basic mode (there are no advanced
parameters) in the server-based application. The Monitoring tab includes the settings of
the Multiviewer output, the OSD information to be displayed, and the downconverted
outputs configuration.
Setting List
The table below presents the settings of the Monitoring tab. They specify where the
setting groups are available (page) and whether each setting is available:
• in the basic and advanced display mode in the server-based and web-based interfaces
• in the Technical Setup menu of the Remote Panel.
Setting Name Basic & Advanced
Technical
Setup
Multiviewer Settings P1 –
Layout X –
Audio Monitoring from video X –
Audio Monitoring left-right tracks X –
Aspect ratio - Videos X –
Aspect ratio - SD downconverted X –
Db15 output X –
HD output format X –
OSD Settings P1 T4.1
Genlock Error X X
Disk Error X X
Network error X X
Clip name X X
Downconverted Outputs Settings P1 T4.2
Char OUT J4 X X
