Example: 3D/1080p Dual Link 1SLSM 2x + 1REC+ 1PLAY
The BNC connectors to be used as record and play channels in a 3D or 1080p Dual Link
configuration 1SLSM 2PH + 1REC + 1 PLAY need to be cabled as shown below:
Note
In an equivalent configuration with a 3G interface, only the J8 connectors are
cabled. However the primary and secondary links on the codec module of the
V3X board are both used.
Available SLSM 3x Configurations
The tables below show the available 3D and 1080p configurations with SLSM 3 Phase
cameras on a XT3 6U server. They show the link assignment at the level of the codec
module of a V3X board.
IN6/OUT1 IN5/OUT2 IN4/OUT3 IN3/OUT4 IN2/OUT5 IN1/OUT6
#REC
SLSM
3x
#REC #PLAY
Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link
1 0 0 REC
1,3A
REC
1,3B
REC
1,2A
REC
1,2B
REC
1,1A
REC
1,1B
1 1 0 REC
2A
REC
2B
REC
1,3A
REC
1,3B
REC
1,2A
REC
1,2B
REC
1,1A
REC
1,1B
1 3 0 REC
4A
REC
4B
REC
3A
REC
3B
REC
2A
REC
2B
REC
1,3A
REC
1,3B
REC
1,2A
REC
1,2B
REC
1,1A
REC
1,1B
2 0 0 REC
2,3A
REC
2,3B
REC
2,2A
REC
2,2B
REC
2,1A
REC
2,1B
REC
1,3A
REC
1,3B
REC
1,2A
REC
1,2B
REC
1,1A
REC
1,1B
1 0 1 PLAY
1A
PLAY
1B
REC
1,3A
REC
1,3B
REC
1,2A
REC
1,2B
REC
1,1A
REC
1,1B
1 1 1 PLAY
1A
PLAY
1B
REC
2A
REC
2B
REC
1,3A
REC
1,3B
REC
1,2A
REC
1,2B
REC
1,1A
REC
1,1B
1 2 1 PLAY
1A
PLAY
1B
REC
3A
REC
3B
REC
2A
REC
2B
REC
1,3A
REC
1,3B
REC
1,2A
REC
1,2B
REC
1,1A
REC
1,1B
