SMC Networks SMC TigerStack III SMC6824MPE - Manual (Page 245)

C
LASS OF
S
ERVICE
C
ONFIGURATION
3-195
Web – Click Priority, ACL CoS Priority. Select a port, select an ACL rule,
specify a CoS priority, then click Add.
Figure 3-88 ACL CoS Priority
CLI – This example assigns a CoS value of zero to packets matching rules
within the specified ACL on port 1.
Changing Priorities Based on ACL Rules
You can change traffic priorities for frames matching the defined ACL
rule. (This feature is commonly referred to as ACL packet marking.) This
switch can change the IEEE 802.1p priority, IP Precedence, or DSCP
Priority of IP frames; or change the IEEE 802.1p priority of Layer 2
frames. (This feature is commonly referred to as ACL packet marking.)
Use the no form to remove the ACL marker.
Console(config)#interface ethernet 1/1 4-174
Console(config-if)#map access-list ip bill cos 0 4-138
Console(config-if)#
