SMC Networks SMC TigerAccess SMC7824M/FSW User Manual
Tigeraccess, Fast ethernet switch
TigerAccess
™
10/100
Fast Ethernet Switch
◆ 24 100BASE-BX Single-Fiber Ports
◆ 2 10/100/1000BASE-T ports shared with SFP slots
◆ 2 module slots for shared 1000BASE-T port / SFP slot
◆ Non-blocking switching architecture
◆ Spanning Tree Protocol, RSTP and MSTP
◆ Up to 12 LACP or static 8-port trunks
◆ Layer 2/3/4 CoS support through eight priority queues
◆ Layer 3/4 traffic priority with IP Precedence and IP DSCP
◆ Full support for VLANs with GVRP
◆ IGMP multicast filtering and snooping
◆ Support for jumbo frames up to 9 KB
◆ Manageable via console, Web, SNMP/RMON
◆ Security features: ACL, RADIUS, 802.1X
Management Guide
SMC7824M/FSW
