C
ONFIGURING THE
S
WITCH
3-112
CLI – This example creates trunk 2 with ports 1 and 2. Just connect these
ports to two static trunk ports on another switch to form a trunk.
Enabling LACP on Selected Ports
Command Usage
• To avoid creating a loop in the network,
be sure you enable LACP before
connecting the ports, and also
disconnect the ports before disabling
LACP.
• If the target switch has also enabled
LACP on the connected ports, the trunk
will be activated automatically.
• A trunk formed with another switch
using LACP will automatically be
assigned the next available trunk ID.
Console(config)#interface port-channel 1 4-174
Console(config-if)#exit
Console(config)#interface ethernet 1/5
4-174
Console(config-if)#channel-group 1 4-194
Console(config-if)#exit
Console(config)#interface ethernet 1/6
Console(config-if)#channel-group 1
Console(config-if)#end
Console#show interfaces status port-channel 1
4-183
Information of Trunk 1
Basic information:
Port type: 100TX
Mac address: 00-30-F1-B3-16-C5
Configuration:
Name:
Port admin: Up
Speed-duplex: Auto
Capabilities: 10half, 10full, 100half, 100full
Flow control: Enabled
Port security: Disabled
Max MAC count: 0
Current status:
Created by: User
Link status: Down
Operation speed-duplex: 100full
Flow control type: None
Member Ports: Eth1/5, Eth1/6,
Console#
active
links
}
}
dynamically
enabled
configured
members
backup
link
