C
LASS OF
S
ERVICE
C
ONFIGURATION
3-179
CLI – This example assigns a default priority of 5 to port 3.
Mapping CoS Values to Egress Queues
This switch processes Class of Service (CoS) priority tagged traffic by
using four priority queues for each port, with service schedules based on
Weighted Round Robin (WRR). Up to 8 separate traffic priorities are
defined in IEEE 802.1p. The default priority levels are assigned according
to recommendations in the IEEE 802.1p standard as shown in the
following table.
The priority levels recommended in the IEEE 802.1p standard for various
network applications are shown in the following table. However, you can
map the priority levels to the switch’s output queues in any way that
benefits application traffic for your own network.
Console(config)#interface ethernet 1/3
Console(config-if)#switchport priority default 5
4-246
Console(config-if)#end
Console#sh interfaces switchport ethernet 1/5
4-186
Information of Eth 1/5
Broadcast threshold: Enabled, 500 packets/second
LACP status: Disabled
Ingress rate limit: disable,100M bits per second
Egress rate limit: disable,100M bits per second
VLAN membership mode: Hybrid
Ingress rule: Disabled
Acceptable frame type: All frames
Native VLAN: 1
Priority for untagged traffic: 5
GVRP status: Enabled
Allowed VLAN: 1(u),
Forbidden VLAN:
Console#
Table 3-11 Mapping CoS Values to Egress Queues
Queue 0 1 2 3
Priority 1,2 0,3 4,5 6,7
