ARM INSTRUCTION SET S3C2440A RISC MICROPROCESSOR
3-2
NOTES
Some instruction codes are not defined but does not cause Undefined instruction trap to be taken, for
instance a multiply instruction with bit 6 changed to a 1. These instructions should not be used, as their
action may change in future ARM implementations.
INSTRUCTION SUMMARY
Table 3-1. The ARM Instruction Set
Mnemonic Instruction Action
ADC Add with carry Rd: = Rn + Op2 + Carry
ADD Add Rd: = Rn + Op2
AND AND Rd: = Rn AND Op2
B Branch R15: = address
BIC Bit Clear Rd: = Rn AND NOT Op2
BL Branch with Link R14: = R15, R15: = address
BX Branch and Exchange R15: = Rn, T bit: = Rn[0]
CDP Coprocessor Data Processing (Coprocessor-specific)
CMN Compare Negative CPSR flags: = Rn + Op2
CMP Compare CPSR flags: = Rn - Op2
EOR Exclusive OR Rd: = (Rn AND NOT Op2)
OR (Op2 AND NOT Rn)
LDC Load coprocessor from memory Coprocessor load
LDM Load multiple registers Stack manipulation (Pop)
LDR Load register from memory Rd: = (address)
MCR Move CPU register to coprocessor
register cRn: = rRn {cRm}
MLA Multiply Accumulate Rd: = (Rm
×
Rs) + Rn
MOV Move register or constant Rd: = Op2
