S3C2440A RISC MICROPROCESSOR CAMERA INTERFACE
23-14
CB4 START ADDRESS REGISTER
Register Address R/W Description Reset Value
CICOCBSA4 0x4F000034 RW Cb 4
th
frame start address for codec DMA 0
CICOCBSA4 Bit Description Initial State
CICOCBSA4 [31:0] Cb 4
th
frame start address for codec DMA 0
CR1 START ADDRESS REGISTER
Register Address R/W Description Reset Value
CICOCRSA1 0x4F000038 RW Cr 1
st
frame start address for codec DMA 0
CICOCRSA1 Bit Description Initial State
CICOCRSA1 [31:0] Cr 1
st
frame start address for codec DMA 0
CR2 START ADDRESS REGISTER
Register Address R/W Description Reset Value
CICOCRSA2 0x4F00003C RW Cr 2
nd
frame start address for codec DMA 0
CICOCRSA2 Bit Description Initial State
CICOCRSA2 [31:0] Cr 2
nd
frame start address for codec DMA 0
CR3 START ADDRESS REGISTER
Register Address R/W Description Reset Value
CICOCRSA3 0x4F000040 RW Cr 3
rd
frame start address for codec DMA 0
CICOCRSA3 Bit Description Initial State
CICOCRSA3 [31:0] Cr 3
rd
frame start address for codec DMA 0
CR4 START ADDRESS REGISTER
Register Address R/W Description Reset Value
CICOCRSA4 0x4F000044 RW Cr 4
th
frame start address for codec DMA 0
CICOCRSA4 Bit Description Initial State
CICOCRSA4 [31:0] Cr 4
th
frame start address for codec DMA 0
