PROGRAMMER'S MODEL S3C2440A RISC MICROPROCESSOR
2-4
R0
R1
R2
R3
R4
R5
R6
R7
R9
R8
R10
R11
R12
R13
R14
R15 (PC)
R0
R1
R2
R3
R4
R5
R6
R7
R9
R8
R10
R11
R12
R13_ svc
R14_ svc
R15 (PC)
R0
R1
R2
R3
R4
R5
R6
R7
R9_ fiq
R10_ fiq
R11_ fiq
R12_ fiq
R13_ fiq
R14_ fiq
R15 (PC)
R8_ fiq
R0
R1
R2
R3
R4
R5
R6
R7
R9
R8
R10
R11
R12
R13_ abt
R14_ abt
R15 (PC)
R0
R1
R2
R3
R4
R5
R6
R7
R9
R8
R10
R11
R12
R13_ irq
R14_ irq
R15 (PC)
R0
R1
R2
R3
R4
R5
R6
R7
R9
R8
R10
R11
R12
R13_ und
R14_ und
R15 (PC)
System & User FIQ Supervisor IRQ Abort Undefined
ARM State General Registers and Program Counter
ARM State Program Status Registers
CPSR CPSR
SPSR_ fiq
CPSR
SPSR_irq
= banked register
CPSR
SPSR_ und
CPSR
SPSR_ abt
CPSR
SPSR_ svc
Figure 2-3. Register Organization in ARM State
